| Feature |
- Specially designed for printing on barrel of wine corks or similar small round items.
- Can print single color only.
- Pneumatically driven to ensure quietness in operation.
- Can be operated in manual and semi-auto mode to suit different worker's skill level.
- Squeegee/flood bar depth, pressure, speed, leveling, and stroke etc., are all adjustable to fit your various printing needs.
- Work table and screen frame are easy to install and dismount.
|
| |
| Specifications |
| Model No. |
SYK1E |
| Max. printing area |
Ø35mm x 75mm (H) |
| Max. printing stroke |
110mm |
| Max. frame size |
200mm x 320mm |
| Max. printing speed |
22 pcs/min |
| Power |
220v 1phase 10W |
| Air pressure |
0.5-0.65 Mpa/cm2 |
| Air consumption |
2 L/min |
| Machine dimension |
710mm x 720mm x 1300mm |
| Packing measurement |
890mm x 900mm x 1540mm |
| Net weight |
119kg |
| Gross weight |
185kg | |
| |
| Standard Accessories |
| Wheeling set |
1 set |
| Squeegees and flood bar |
1 set |
| Adjustment tools |
1 set |
| Operation manual |
1 set | |
| |
| Optional Accessories |
|
Screens
Inks and thinners |
